Specifications
Product Details
| Product Name | Tensioner With Bow Shackle |
| Item Number | HF-S002 |
| Material | Stainless Steel 304/316 |
| MOQ | 100pcs |
| Certificate | ISO9001 |
| Place of Origin | Shandong,China |
|
OEM |
Accepted |
| Sample |
Acceptable |
Description
The Tensioner with Bow Shackle is a stainless steel device used to apply tension in wire rope systems. It is designed for safety railings, fall arrest systems, and structural cable applications. The tensioner includes a central body with thread and two bow shackles on both ends.
The bow shackle creates a flexible connection. It can rotate slightly under load. This helps absorb small movements. It also reduces stress at the anchor points. The pin on the shackle can be removed. This makes it easy to install or replace the cable.
The threaded body connects the two shackles. You can turn the body to increase or reduce the wire rope tension. The design allows for precise adjustments. You can make changes after the rope is fixed. Lock nuts can be added to hold the position.
This product is made of marine-grade stainless steel. It is resistant to corrosion, even in wet or salty air. It can be used outdoors for long periods. It is also suitable for rooftops, stair barriers, and public fencing systems.
The tensioner supports mid-level loading. It is not made for lifting. It holds cables firmly in position. The smooth finish fits well in modern building styles. It also improves safety by keeping cables tight.
No special tools are needed. You can tighten the rope with a standard wrench. All parts can be removed and reused. This helps reduce maintenance costs.
FAQ
Q: Can the bow shackle rotate after installation?
A: Yes. It allows some movement to reduce stress but stays secure under load.
Q: Is this product suitable for use on rooftops?
A: Yes. It can be used for rooftop safety cables or barriers. It resists rust and weather damage.
Q: Does this tensioner need welding or crimping?
A: No. It uses threaded parts and shackles. Installation is done with simple hand tools.
Q: How do I know if the tension is correct?
A: You can measure the cable tension manually or visually check for slack. Tighten until the rope is firm.
Q: Can I replace only the bow shackle?
A: Yes. Each shackle can be removed separately. You can change one without replacing the full tensioner.
